Compressed-air angle grinder PWAS 4/70

Air-powered angle grinder PWAS 4/70 HV 90° 7000 RPM/350 watts

PWAS 4/70 HV 90°

Item number:: 80209007
EAN:: 4007220894408

Air-powered angle grinder PWAS 4/70 HV 90° 7000 RPM/350 watts 2

Air-powered angle grinder PWAS 4/70 HV 90° 7000 RPM/350 watts 3

Technical data

Retailers-Search

Technical information

Air-powered angle grinder PWAS 4/70 HV 90° 7000 RPM/350 watts

Air consumption, at idle: 0.7 m³/min
Air consumption, under load: 0.6 m³/min
Air supply hose internal dia.: 8 mm
Angle head: 90°
Collet group: 6
Exhaust direction: rear
Height: 67 mm
Incl. dia collet [mm]: 6 mm
Length: 228 mm
Net weight of the machine: 1.145 kg
Number of oil drops [min]: 3 drops
Operating pressure: 6.3 bar
Power output: 350 watts
Rotational speed: 7000 RPM
Throttle type: Lever
Version: compact design
Width: 39 mm
Packaging unit: 1 piece

Description

The drive is equipped with a collet tool mounting for mounted tools.

The exhaust direction the air grinder is at the back.

Sophisticated air-powered angle grinder with exhaust directed to the rear, dead man’s switch using safety lever valve and collet. The drive may only be used with oil.

Special features

No dust turbulence on the workpiece side.
The 90° angle head is ideally suited to working in hard-to-reach areas.
The drive has a particularly high torque thanks to the reduction gear.

Safety notes

The drive must be operated with the specified number of oil droplets in order to prevent premature malfunctioning.

Contents

1 m exhaust hose and 2.5 m air supply hose with 1/4" male threaded connection and threaded quick coupling (STGI), collet SPZ GR.6 6 mm), 2 keys (1x EM SW 11 mm, 1x EM SW 14 mm).
